ECOFLOW 45W Portable Solar Panel, 25% High Conversion Efficiency

ECOFLOW 45W Portable Solar Panel, 25% High Conversion Efficiency

25.000 KWD
25.000 KWD
Sale Sold out
Shipping calculated at checkout.
  • Model  : EF-Fold-P045-DT
  • Rated Power : 45W (±5W)
  • Open Circuit Voltage (Voc)  : 25.6V
  • Short Circuit Current (Isc) : 2.06A
  • Max Power Voltage (Vmp) : 22V
  • Max Power Current (Imp)  : 1.98A
  • Recommended Ambient Temperature : -20°C to 85°C
  • Efficiency : 25%
  • DC5521 Output : 45W (±5W) 22V/1.98A
  • Type-C Output  : 15W Max (5V/3A)
  • Temperature Coefficient of Rated Power :  –(0.30±0.02)%/°C
  • Temperature Coefficient of Open Circuit Voltage  :  –(0.25±0.03)%/°C
  • Temperature Coefficient of Short Circuit Current:  +(0.045±0.015)%/°C
  • Dimensions
  • Weight : Approx. 1.4 kg (3.09 lbs)
  • Unfolded Dimensions (L×W×H)  :  980×309×16 mm (38.58×12.17×0.63 in)
  • Folded Dimensions (L×W×H) :  222×309×40 mm (8.74×12.17×1.57 in)
  • Battery Specifications
  • Cell Type : TOPCon monocrystalline silicon
  • Connector Type : DC5521/Type-C
  • Standard Test Conditions : 1000W/m² (92.9W/ft²), AM1.5, 25°C (77°F)
  • When the temperature is too high or too low, the panel's open circuit voltage and
  • short circuit current will vary.
